FULL AUTOMATIC VERTICAL PACKAGING MACHINE

Category:

Vertical Packaging Machine

Commodity name： FULL AUTOMATIC VERTICAL PACKAGING MACHINE

Commodity ID:

It applies for measuring and packaging various shapes of materials, such as candy, chocolate, biscuits, puffed food, etc.

Brand:
JINHONG

Keyword:Food machinery

Service:

Product Description

Product:
Candy, chocolate, biscuits, puffed food, etc.

Technical Parameters:

Model	Output	Voltage	Power	Weight	Packaging Bag Dimension	Machine Dimension
JH-V320	40-90 packs/min	220V/50Hz	3 kW	350 kg	Length 60-180 mm/ Width 50-150 mm	12209001350 mm
JH-V420	30-80 packs/min	220V/50Hz	5 kW	500 kg	Length 80-300 mm/ Width 80-200 mm	132010501420(+350) mm
JH-V520	35-65 packs/min	220V/50Hz	6 kW	600 kg	Length 100-350 mm/ Width 100-250 mm	150011501520 mm
JH-V720	10-40 packs/min	220V/50Hz	6 kW	700 kg	Length 100-500 mm/ Width 200-350 mm	165014001900 mm

Machine Design:
√PLC servo system, pneumatic control system and large display touch screen constitute the drive control core. Maximize the control accuracy, reliability and intelligence of the whole machine.

√ Intelligent temperature controller is adopted to ensure accurate temperature control, beautiful and smooth sealing.

√ It is equipped with fault display system, which can eliminate faults in time.

√ The touch screen can store the packaging process parameters of a variety of different products, which can be used at any time when changing products without resetting.

√ This machine and metering device can automatically complete the whole packaging process of metering, feeding, filling and bag making, date printing, inflation (exhaust), and finished product transportation, and automatically complete the counting.

√ It can be integrated with multi-head computer combined scale, screw scale, filling machine, screw elevator, granulator, Z-type elevator, etc

√ Pillow bags, hole punch bags, etc. can be customized according to customer needs.

Benefits:
√ Excellent package and sealing quality

√ High performance and high efficiency

√ Easy for cleaning and maintenance

√ Easy operation and high operational safety

√ Excellent hygiene standards
